Geodetic Total Station Dtm 692r Single Prism Total Station 3000m

PRODUCT SHOWPRODUCT SPECIFICATIONDTM692 -- WINCE Non-Prism Laser Ranging Total StationDistance Measurement SectionRangeNon-prism400m and 600m for optionalprismSingle prism3000mThree prism5000mAccuracyNon-prism±(3mm+2ppm·D)Prism±(2mm+2ppm·D), ±(3mm+2ppm·D)Unitm/ftDisplayMaximum99999999.99

Featured Products

PRODUCT SHOW
Dadi Total Station Dtm 692r Total Station with Single Prism 3000m
PRODUCT SPECIFICATION

DTM692 -- WINCE Non-Prism Laser Ranging Total Station
Distance Measurement Section
Range
Non-prism
400m and 600m for optional
prism
Single prism
3000m
Three prism
5000m
Accuracy
Non-prism
±(3mm+2ppm·D)
Prism
±(2mm+2ppm·D), ±(3mm+2ppm·D)
Unit
m/ft
Display
Maximum
99999999.9999m
Minimum
0.1mm
Measuring time
Precise model:1S, Track model:0.8S
Number of time Set
1 ~ 99
Meteorologiccorrection
Input the value and correct automatic
Prismconstant
Input the value and correct automatic
Angle Measurement Section
Method
Absolute coding
Grating diameter
79mm
Minimum reading
1″
Detection
Horizontal
Diametrical detection
Vertical
Diametrical detection
Accuracy
2″
Telescope Section
Imaging
Positive
Length
170mm
Effectiveaperture
48mm
Magnification
30×
Angle of vision
1.5°
Distinguishability
3.5″
Minimum focus distance
1.5m
Compensator
System
Double axis photoelectric tilt sensor or
Single axis liquid tilt sensor
Working range
±3′
Distinguishability
1″
Display Section
Type
Double sides,320×240 LCD Display
Data Transmission
Port
Bluetooth,SD Card,USB,RS-232C
Capacity
40,000 data at least
Others
Plummet
Optical or Laser plummet
Power
Rechargeable lithium battery,DC7.4V,3600mAh
Continuous working time
4 hours at least
Size
174×207×383mm
Weight
6.8Kg
Working temperature
-20ºC ~ 50ºC
PACKING & SHIPPING

Dadi Total Station Dtm 692r Total Station with Single Prism 3000m
PAYMENT

Dadi Total Station Dtm 692r Total Station with Single Prism 3000m

COMPANY INFORMETION

Shanghai Hexin Survey Instrument Co., LTD has 8 years' experience in geodetic surveying and cadastration surveying, we are a professional and leading enterprise in the surveying industry in MainlandChina. We specialize in the R&D and manufacturing and sales of all kinds of surveying products, including total station, electronic theodolite, electronic distance meter, automatic level, laser level, reflector prism, surveying  accessory, GPS receiver, mapping software, etc.The marketing model advocated by us is not a simple sense of "selling products", instead, pre-sales service, services  during operation and after-sales service are integrated in entire operating activities. It makes the customers feel that they purchased not only a commodity, but also a professional service.We welcome new and old customers from all walks of life to contact us for future business relationships and achieving mutual success!

Dadi Total Station Dtm 692r Total Station with Single Prism 3000m

FAQ

Q:How to turn off voice broadcast of receiver?
A: a. Enter the WEBUI, find the voice switch in the settings page and turn it off.

b. Controller Software→Device→Device Setting, turn off the "enable voice", and click"ok"

Q: Can the base station and rover station be interchangeable?
A: The difference between the rover station and the base station is that the accessories are different, the function and hardware configuration are the same.You can use the controller to choose the working mode of the device and set it as the base station or rover station.

Q: What is CORS?
A: CORS is called a continuous operating reference station system. It can be understood as a bas e station that is erected at a fixed known point and works continuously for 24 hours and sends its own data to a specific
serverthrough the network. The use of CORS operation eliminates the need for a base station, and CORS is equivalent to a base station in a normal network operation.
